HSD ES919A 8kW Air-Cooled CNC Spindle Motor ISO30 220/380V 2P
For sale is a HSD ES919A 8kW Air-Cooled CNC Spindle Motor ISO30 220/380V 2P.
Industrial CNC spindle motor by HSD Mechatronic Division.
Model: ES 919A (ES919). Air cooling. Asynchronous 3?phase, 2-pole.
Nameplate power: 8.00 kW. S1 continuous 6.6 kW (8.9 hp). S6 60% 8 kW.
Peak 19 kW (25.5 hp).
Rated voltage: 220 V or 380 V, 200 Hz. Nameplate current: 27.4 A (220
V) / 15.8 A (380 V).
Max RPM options listed on label: 20k / 24k / 28k / 30k (exact
programmed limit not confirmed).
Tool interface: ISO 30, DIN 69871. Manual tool release indicated; two
pneumatic ports present. IP54.
Includes the spindle assembly with attached mounting base and pigtail
wiring as shown. No toolholder, collet, or external cables included.
Condition: Used with scuffs, scratches, and some oxidation,
particularly at the fan end; cable ends are cut. See photos.
Typical use: CNC routers and machining centers for wood, plastics,
composites, and light metals.
Assumption: Removed from service and not tested by us.
